Overview
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") | |
| UniFi Application Suite | ||
| - | Network | ✓ |
| - | Protect | ✓ |
| - | Access | ✓ |
| - | Talk | ✓ |
| - | Connect | ✓ |
| Managed UniFi Devices | 200+ | |
| Managed Cameras | (50) HD (25) 2K (15) 4K | |
| Simultaneous Users Connected | 2,000+ | |
| Default WAN Ports | (1) 10G SFP+ (1) 2.5 GbE RJ45 | |
| LAN Ports | (1) 10G SFP+ (8) GbE RJ45 | |
| IDS/IPS Throughput | 5 Gbps | |
| Form Factor | Rack mount (1U) | |
| Redundancy | Shadow Mode (VRRP) Gateway Failover DC Power Backup | |
Security
| Stateful Firewall | ✓ | |
| Application-Aware Layer 7 Firewall | ✓ | |
| DPI & Traffic Identification | ✓ | |
| Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) | ✓ | |
| Content Filtering | ✓ | |
| Intrusion Prevention (IPS/IDS) | ✓ | |
| Ad Blocking | ✓ | |
| IDS/IPS Signatures | 55,000+ with CyberSecure | |
| VLAN/Subnet-based Traffic Segmentation | ✓ | |
VPN & SD-WAN
| License-Free SD-WAN | ✓ | |
| Site-to-Site VPN | ||
| - | Site Magic | ✓ |
| - | IPsec | ✓ |
| - | OpenVPN | ✓ |
| VPN Server | ||
| - | Identity Endpoint One-Click VPN | ✓ |
| - | Teleport Zero-Configuration VPN | ✓ |
| - | WireGuard | ✓ |
| - | OpenVPN | ✓ |
| - | L2TP | ✓ |
| VPN Client | ||
| - | OpenVPN | ✓ |
| - | WireGuard | ✓ |
Networking
| Multi-WAN Load Balancing | ✓ | |
| Shadow Mode (VRRP) High Availability | ✓ | |
| Dynamic Routing | ||
| - | OSPF | ✓ |
| - | BGP | ✓ |
| Advanced QoS | ✓ | |
| Multicast DNS (mDNS) | ✓ | |
| Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) | ✓ | |
| Integrated RADIUS Server | ✓ | |
| RADIUS over TLS (RadSec) | ✓ | |
| Additional Internet Failover with UniFi LTE Backup | ✓ | |
| Internet Quality and Outage Reporting | ✓ | |
| MAC Address Table Size | 4,000 | |
| Policy-based WAN and VPN Routing | ✓ | |
| Customizable DHCP Server | ✓ | |
| IPv6 ISP Support | ✓ | |
| IGMP Proxy | ✓ | |
Hardware
| NVR Storage | (2) 3.5" NVR HDD bays Built-in 128 GB SSD for Faster Experience | |
| Max. Power Consumption | 60W | |
| Power Method | (1) Universal AC input, 100-240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 8.7A | |
| Power Supply | AC/DC, internal, 100W | |
| Supported Voltage Range | 100—240V AC | |
| Processor | Quad-core ARM® Cortex®-A57 at 2.0 GHz | |
| System Memory | 8 GB | |
| On-board Storage | 32 GB eMMC 128 GB SSD (Integrated) | |
| Weight | 4.7 kg (10.4 lb) | |
| Enclosure Material | Aluminium CNC, SGCC steel | |
| Mount Material | SGCC steel | |
| LCM Display | 1.3" touchscreen | |
| Management | Ethernet Bluetooth | |
| LEDs | ||
| - | Ethernet | ✓ |
| - | SFP+ | ✓ |
| - | RPS | ✓ |
| - | PSU | ✓ |
| - | HDD | ✓ |
| ESD/EMP Protection | Air: ± 15kV, contact: ± 8kV | |
| Ambient Operating Temperature | -10 to 40° C (14 to 104° F) | |
| Ambient Operating Humidity | 5 to 95% noncondensing | |
| Certifications | CE, FCC, IC | |
| Button | (1) Factory-reset | |
